Deflection shape presentation

_images/image_deflection_shape_prs.png

Deflection shape is a type of field presentation when vector values corresponding to the mesh cells are visualized by shifting these cells.

To create a Deflection shape presentation,

  • Select a field item in the Object Browser, and

  • Choose Presentations > Deflection shape menu or click img_dfl button in the Presentations toolbar.

As a result, Deflection shape presentation is published in the Object Browser under selected field and displayed in the 3D Viewer.

Deflection shape presentation has the same base parameters as Scalar map presentation.
